仕様
| アイテム | パラメータ | ||
| Battery model | AIN106090 | ||
| 公称電圧 | 3.7V | ||
| 最小容量 | 7000mAh | ||
| 充電電圧 | 4.2V | ||
| 放電終止電圧 | 3.0V | ||
| 標準充電 | 0.2C /4.2V | ||
| Max charging | 1.0C /4.2V | ||
| Standard discharging | 0.2C / 3.0V | ||
| Max discharging
| continuous discharge | 1.0C / 3.0V | |
| non-continuous discharge | 2.0C / 3.0V | ||
| Shipment voltage | ≥3.85V | ||
| Battery pack impedance | |||
| 使用温度
| 充電:0°C〜45°C | ||
| Discharging: -20°C ~60°C | |||
| Storage (At 50% SOC and specified temp, recoverable capacity in % vs time ) | -10℃~25℃ (12 months ≥85% ) | ||
| -10℃ ~45℃ (6 months ≥85% ) | |||
| -10℃~55℃ (1 month ≥90% ) | |||
| 20±5℃は推薦された貯蔵温度です | |||
| 外観検査 | There should not be any remarkable scratches, cracks, bolts, cauterization, deformations, swelling, leakage and so on the surface of the cell. | ||

2.環境にやさしい
3. Long cycle life, chargeable up to 500 times
4. Low internal resistance
5. Short-circuit production function, safe and reliable
6. Good consistency, low self-discharge
7. Can be customized numerous sizes
8. Wide application for electronics and industry
we promise
1.すべての製品は出荷前に100%テストされ、製品に品質上の問題がないことを確認します。
2.商品の受け取り日から12か月以内に、人為的損傷が含まれないことを保証します。品質に問題がある場合は、返品サービスを提供します。
顧客サービス
1.OEM ODM service is acceptable.
2.1000個までのご注文で、サンプル料金を返金いたします。
応用

私たちの工場




We can provide you with customized services.
Customized different voltage and capacity lithium polymer battery.
The capacity and dimension can customize according to your request
1.カスタマイズされたバッテリーサイズとシェル材質。
2.Customized protection board charging and discharging current.
3.カスタマイズされた接続プラグとソケット、コネクタワイヤ。
梱包と配送

| Shipping options | Recommend | 納期 | |
|
Express | DHL | widely recommend | 3-7 business days |
| UPS | widely recommend | 3-7 business days | |
| FEDEX | recommend | 5-7 business days | |
| TNT | recommend | 5-7 business days | |
| EMS | widely recommend | 5-10 business days | |
| Post mail | for sample order | 7-60 business days | |
| Airfreight | for sample order | 5-7 business days | |
| By sea | for sample order | 7-35 business days |
よくある質問
1、Q:ALL IN ONEの主な製品は何ですか?
A:充電式バッテリー。 Li-ion、Lipoバッテリー、パワーバッテリーパック。
2、Q:過充電とは何ですか?
A:充電後、バッテリーの初期状態と容量をテストしました。 3C電流で10.0Vに充電してから、CVモードで0.01Cに充電します。
バッテリーの外観の変化を観察します。
3、Q:過放電とは何ですか?
A:充電後、バッテリーの初期状態をテストしてください。電池が正常になったら、0.5Cで0Vまで放電してください。の変化を観察する
バッテリーの外観。
4. Q:サンプル注文はできますか?
A:はい、品質をテストおよびチェックするためのサンプル注文を受け付けています。電池は必要に応じて作ることができます。
5. Q:MOQの制限はありますか?
A:はい、量産にはMOQ制限がありますが、バッテリーのモデルによって異なります。詳しくはお問い合わせください。
6. Q:リードタイムはどうですか?
A:サンプルには5〜7営業日かかります。大量生産には25〜30日かかります。数量によります。
7. Q:発送と配達の時間はどうですか?
A:通常、バッテリーはDHL、TNT、FedEx、UPSなどのExpressで発送され、配達時間は3〜5営業日です。またはDDP
サービス、配達時間は11-15営業日です。航空会社と海上輸送もご利用いただけます。
8. Q:アフターサービスはどうですか?
A:1年間の保証を提供します。何か問題がありましたら、お知らせください。前向きな解決策を提供します。
